Single Receiver
Product
RM3-S1-x103K-R

OptoMedia 3G-SDI optical receiver SFP perfectly converts SDI optical signals at SMPTE 424M, SMPTE 292M, SMPTE 259M and DVB-ASI to electrical signal. It supports data rate 2.97Gbps and handles pathological patterns.
  • 4-RM3-S1-4103K-R
  • 2-RM3(C)-S1-3103K-T(R0)
  • 3-RM3-S1-2103K-T0(R0)
  • Support SMPTE 424M, SMPTE 292M, SMPTE 259M, DVB-ASI
  • Handles pathological patterns for 3G-SDI, HD-SDI and SD-SDI
  • Digital diagnostics function
  • 10km over single mode fiber
  • Low power consumption- Typical 100 mA
  • Available in MSA and Non-MSA pinouts
  • LC, ST, SC of connectors to choose from
Parameter Min Typ Max
Wavelength (nm) 1260   1620
Operating case temperature range (℃) 0   70
Storage temperature range(℃) -40   85
Power supply voltage (V) 3.1 3.3 3.5
Power consumption (mA)   100 150
